double station blow molding machine AMB70D

Ask Lasest Price
Brand Name :	Aman
Model Number :	AMB70D
Certification :	CE
Delivery Time :	From 10-30 Working Days
Payment Terms :	LC, TT, Etc.

Add to Cart

Product Details
Company Profile

double station blow molding machine AMB70D

double station blow molding machine

Parameters
Specifications	AM70series
Material	PE,PP….
Max container capacity	3--5--10L
Number of die	1set
Output(dry Cycle)	1000pc/hr
Machine Dimension(L×W×H)	3.5x2.2x2.8M
Total weigh	7.1ton
Clamping Unit	AM70series
Clamping force	105KN
Platen opening stroke	200-550mm
Platen size	500x550mm
Max mould size(W×H)	550x500mm
Mould thickness	210-300mm
Power	AM70series
Max drive	27.5KW
Total power	48.5KW
Fan power for screw	0.54KW
Air pressure	0.7Mpa
Air consumption	0.6m³/min
Average energy consumption	18.5KW

1.there will be more space on the work table , and then it's easy to install the molds. the core rod's gyration semidiameter is more than before ,now the products' height is increased to 175mm.

2.high-pressure hydraulic clamping device use accumulator to hold presure ,to improve productivity and save energy.

3.the work table is cast by ductile cast iron ,and it is more thick ,more strong and more steady

4.figure is be improved ,it will hold much less space, and looks nice.

double station blow molding machine AMB70D
